Rotor Pump with Special Pump Cover

Rotor Pump with Special Pump Cover

In conventional rotary lobe pumps, the shaft typically features a cantilever design. As the outlet pressure increases, the discharge pressure places additional stress on the shaft, which may cause it to bend or deform near the pump inlet and result in internal contact.

The newly designed pump cover incorporates an additional set of sliding bearings to improve the load-bearing capacity of the pump shaft.

Categories: , ,
Read MoreClose

Technical Parameters

Item Type Capacity (L/r) Rotation speed (r/min) Rated flow （m³/h) Dischare pressure （Mpa） Power （kw) Suction pressure （Mpa） Viscosity （cp） Standard Port size (mm) Enlarged Port size (mm)
1 15TLS12-0.5C 0.04 10-720 0.5 0.1-1.2 0.25-1.5 0.08 10-1000000 15 25
2 25TLS12-2C 0.15 10-720 2 0.1-1.2 0.25-2.2 0.08 10-1000000 25 40
3 40TLS12-5C 0.32 10-500 5 0.1-1.2 0.37-3 0.08 10-1000000 40 50
4 50TLS12-10C 0.65 10-500 10 0.1-1.2 1.5-7.5 0.08 10-1000000 50 65
5 60TLS12-15C 1.1 10-500 15 0.1-1.2 2.2-11 0.08 10-1000000 65 80
6 65TLS12-20C 1.74 10-500 20 0.1-1.2 2.2-15 0.08 10-1000000 65 80
7 75TLS12-30C 2.6 10-500 30 0.1-1.2 3-22 0.08 10-1000000 80 100
8 80TLS12-40C 3.65 10-500 40 0.1-1.2 4-30 0.08 10-1000000 100 125
9 100TLS12-60C 5.2 10-500 60 0.1-1.2 5.5-45 0.08 10-1000000 125 150
10 125TLS12-80C 6.8 10-500 80 0.1-1.2 7.5-55 0.08 10-1000000 125 150
11 140TLS12-120C 9.8 10-400 120 0.1-1.2 11-75 0.08 10-1000000 150 200
12 150TLS12-150C 12.8 10-400 150 0.1-1.2 15-110 0.08 10-1000000 150 200
13 200TLS12-200C 15 10-300 200 0.1-1.2 18.5-132 0.08 10-1000000 200 250
14 250TLS12-300C 20 10-300 300 0.1-1.2 22-160 0.08 10-1000000 250 300
15 300TLS12-400C 30 10-300 400 0.1-1.2 37-220 0.08 10-1000000 300 350
16 320TLS12-500C 40 10-280 500 0.1-1.2 45-280 0.08 10-1000000 300 350
17 350TLS12-650C 50 10-280 650 0.1-1.2 55-355 0.08 10-1000000 350 400
18 370TLS12-800C 60 10-260 800 0.1-0.6 55-220 0.08 10-1000000 350 400
19 400TLS12-900C 70 10-260 900 0.1-0.6 75-280 0.08 10-1000000 400 450
20 420TLS12-1000C 80 10-260 1000 0.1-0.6 90-355 0.08 10-1000000 400 450
Note:  The capacity in the sheet  is for tri-impeller rotor.

Product Performance

  1. A clearance is maintained between the rotors and between the rotors and pump body, preventing friction and extending service life.
  2. Simple assembly and disassembly make the pump easy to maintain and clean, with fewer wear parts.
  3. High efficiency and energy savings, with a low failure rate, reliable sealing and low noise.
  4. Different rotor types can be interchanged within the same pump model.
  5. Capable of pumping viscous media ranging from 1 cP to 2,000,000 cP.
  6. Capable of pumping mixtures of gas, liquid and solid media.
  7. When equipped with an inverter, the flow rate can be adjusted according to the end user’s requirements.
  8. Flange, threaded or clamp connections can be selected as required.
  9. High hygienic standards with CIP and SIP compatibility. Surface roughness ranges from 0.2 to 0.8 μm, with 3-A and FDA certification.
  10. The hygienic safety valve features a built-in design.
