JUNIORFLUX Pump Kit for small quantities

The small sealless barrel pump JUNIORFLUX with fixed motor FEM 3070 is particularly suitable for filling comparatively small quantities from containers such as canisters up to 200 l drums. The small outer tube diameter allows conveying even from narrow openings. The pump set consists of pump with motor, 2 m hose line and nozzle.

Categories: , ,
Read MoreClose

Technical Data

  • Flow rate: max. 57 l / min
  • Delivery height: max. 8.5 mWs
  • Viscosity: min. 1 mPas - max. 250 mPas
  • Outer tube diameter: min. 25 mm - max. 32 mm
  • Immersion depth: 700, 1000
  • Material outer tube: polypropylene
  • Media / Fluids: acids, alkalis
  • Seal: sealless
  • Containers: canisters, hobbocks, 200 liter barrels

Product Features

  • In the media area sealless
  • With mains connection
  • Brushed powerful collector motor
  • Ergonomically designed handle
  • Low weight
  • Small outer tube diameter
  • Fastening hook for fuel nozzle at the discharge nozzle
  • With integrated bracket for hanging the pump

Advantages

  • Also suitable for filling smaller quantities
  • Can promote from narrow-necked containers
  • Minimal effort when changing the barrel
  • With mains connection - very long operating time possible
  • High operational safety through overcurrent circuit breaker
  • Simple one-hand operation
  • Fuel nozzle always easy to reach with fastening hooks
  • Can be stored in a space-saving manner

Suitable Applications - media examples

  • battery acid
  • ammonia water
  • glycols
  • sodium hydroxide
  • soap solution
  • boric acid
  • phosphoric acid
  • hydrochloric acid
  • Sulfuric acid (up to 80%)
  • fruit acids

Consists of

  • JUNIORFLUX pump F 314 PP
  • with integrated collector motor FEM 3070; 230 volts, 50 Hz, 230 watts
  • PVC hose line 2 m
  • Fuel nozzle made of polypropylene
